Champak Steel Stockist and manufacturers of 460 Yield Steel Plate, Supplier of 460 Yield Steel Plate India.
460 Yield Steel PlateDesigners are increasingly using 460 MPa yield plate to combine increased strength with savings in Weight.
With availability in both structural and pressure vessel grades in a wide range of plate sizes and thicknesses Champak Steel & Engg. Co. provides your stock answer.
We recognise the need for an ex-stock source of 460 yield plate and are able to offer the following material:





Send Online Enquiry
W

  • 460 Yield Steel Plate EN 10028-3 P460NL1/2
  • 460 Yield Steel Plate EN 10028-3 P460NH
  • 460 Yield Steel Plate EN 10025-3 S460N
  • 460 Yield Steel Plate Sailma 450Hi
  • 460 Yield Steel Plate IS 2062 E450A
  • IS 2062 E450D
  • 460 Yield Steel Plate IS 8500 FE 570

460 Yield Steel Plate Applications
:
    • Bridges
    • Grouted tees/Grouted sleeves
    • Pipe caps/Pipe fittings
    • Pipe lines
    • Plate girders
    • Pressure vessels
    • Road tankers

      Send Online Enquiry


460 Yield Steel Plate Technical Specifications :

460 Yield Steel Plate Chemical Composition (Ladle %)
C
max
Si
max
Mn
max
P
max
S
max
Al total
min
N
max
0.20 0.60 1.10 to 1.70 0.020 0.005 0.020 0.025

Chemical Composition (Ladle %)
Cr
max
Cu
max
Mo
max
Nb
max
Ni
max
Ti
max
V
max
0.30 0.70 0.10 0.05 0.80 0.03 0.20

Nb + Ti + V Carbon Equivalent
0.22% Max Up to 30mm thick  0.50% max
Over 30mm thick  0.53% max

460 Yield Steel Plate Mechanical Properties
Product Thickness Yield Strength
MPa (min)
Tensile Strength
MPa
Elongation % (min)
< 16mm 450 570 to 730 17
16 to 50mm 450 570 to 720 17
> 50mm 430 570 to 720 17

Minimum Impact Values Transverse Direction
460 Yield Steel Plate Grade -50 -40 -20
460 Yield Steel Plate P460NH -- -- 30J
460 Yield Steel Plate P460NL1 -- 27J 35J
460 Yield Steel Plate P460NL2 27J 30J 40J
460 Yield Steel Plate SAILMA 450Hi -- -- 27J
460 Yield Steel Plate IS 2062 E:450D -- -- 27J
460 Yield Steel Plate IS 2062 E:450A -- -- 27J
460 Yield Steel Plate IS 8500 FE:570 -- -- 27J
Applicable for plate thickness less than 250mm

460 Yield Steel Plate Size range
:

EN 10028 P460 NL1 / NL2 / NH - EN10025-3 S460 N / NL1
Thickness: 6/8/10/12/16/20/25/32/36/40/45 Length: 5000-12000 Width:1500-3000
Thickness: 50/55/60mm Length: 5000-12000 Width:1500-3000
